E-Mini 500 Electric Youth ATV | 36V 500W Motor | 6-Inch Tires & Disc Brakes

The E-Mini 500 delivers impressive performance in a compact electric package. Powered by a 36V 500W high-speed motor paired with a 39V 12A lead-acid battery, this vehicle achieves a 12.4-mile range on a single charge. The chain-drive transmission ensures reliable power delivery, while dual mechanical disc brakes provide confident stopping control. Equipped with 6-inch tires and a sturdy frame, it accommodates riders up to 176.4 lbs. At just 112.4 lbs, the E-Mini 500 balances durability with portability, making it an efficient choice for short-distance commuting and recreational riding.

EV Power & Performance

• Motor: 36V 500W High-Speed Motor
• Battery: 39V 12A Lead-Acid Battery
• Transmission: Chain Drive
• Range: 12.4 miles

Chassis, Wheels & Brakes

• Brakes: Front and Rear Mechanical Disc Brakes (Cable operated / Handbrake
• Tires: 6-inch (with inner tubes)
• Front Tire Size: 4.1-6
• Rear Tire Size: 13 x 5.00-6

Dimensions & Capacity

• Vehicle Dimensions (L x W x H): 41.7 x 24.8 x 30.7 in
• Handlebar Height: 30.7 in
• Seat Height: 19.3 in
• Max Load: 176.4 lbs

Weight & Packaging

• Net Weight: 112.4 lbs
• Gross Weight: 125.7 lbs
• Standard Package Size: 42.1 x 25.2 x 23.6 in
• Export Packing Size: 39.8 x 24.0 x 20.5 in
